Full-outdoor V-band Microwave Device for Network Transmission by Huawei OptiX RTN 360

Products Description

Huawei Full-outdoor V-band Base Stations Microwave Device OptiX RTN 360

Micro base stations are an important part of the mobile backhaul solution. Micro base stations provide network access anytime and anywhere, and therefore they can provide abundant bandwidth resources for hotspot areas and cover blind spots.

The RTN 360 is Huawei's first full-outdoor V-band device that operates in 59-64 GHz frequency bands (license-free in most areas) and integrates the baseband unit, RF unit, and antenna into one chassis. As the RTN 360 is lightweight and small, it improves the efficiency of deploying micro base stations and reduces maintenance costs.

Full-outdoor V-band Microwave Device for Network Transmission by Huawei OptiX RTN 360

TECHNICAL SPECIFICATION

Microwave Type	IP microwave over Native Ethernet/PWE3 Ethernet
Frequency Band	59-64 GHz
Duplex Mode	TDD
Channel Bandwidth	200 MHz
Modulation Scheme	QPSK, 16QAM, 32QAM
Port Type	Auxiliary port	USB port, NMS port
		Service port	Two fixed GE electrical ports, one of which can serve as a power over Ethernet (P&E) port
Capacity	• Maximum air-capacity bandwidth: 600 Mbps
		• Maximum air-interface throughput: 1.6 Gbps
		• Switching capacity: 8 Gbps
RF Configuration	1+0
Service Type	• Native Ethernet: E-Line, E-LAN
		• PW-based Ethernet services: E-Line, E-Aggr, E-LAN (VPLS)
NMS	NCE, Web LCT, SNMP
Ethernet OAM	IEEE 802.1ag, IEEE 802.3 ah, ITU-T Y.1731
Key Features	AM, ATPC, TDD, Automatic Frequency Selection, ERPS, QoS/HQoS,Bandwidth Notification, TWAMP Light, Anti-theft
Clock Features	• Supported clock sources: microwave link clock, synchronous Ethernet clock
		• IEEE 1588v2 time synchronization
		• ITU-T G.8275.1 time synchronization
Power Supply Mode	P&E, generally used in conjunction with the RTN PI
Antenna Type	Built-in panel antenna
Antenna Gain	36 dBi
Dimension	192.5 mm x 192.5 mm x 70 mm
Weight Typical Power	2.5 kg
Consumption	20 W
Environment	• Temperature: -33ºC to +55ºC
		• Humidity: 5% to 100%
